Crystal Series
Product information
Starts from $10,000
Description
The Crystal Series offers clarity transformed with transparency for indoor LED video walls
Highlights
- Easy Installation and Maintanance
- Lightweight Design
- Transperancy of 60%
Details
Crystal Series includes models with pixel pitches of P2.8*5.6 and P3.9*7.8, offering high transparency and clarity

Clarity Transformed with Transparency
Experience clarity transformed with transparency with the Crystal Series

Easy Installation and Maintanance
Lightweight Design


Transperancy of 60%
Technical Specifications
The product features are precision crafted to deliver exceptional performance and aesthetics.
- Model
- Crystal Series
- Pixel Pitches
- P2.8*5.6, P3.9*7.8
- Cabinet Dimension (mm)
- 1000 x 1000 x 20, 970 x 870 x 15
- Material
- Aluminum
- Pixel Configuration
- 1R1G1B Tri-in-one SMD LED
- LED Chip Type
- Samsung: 1921
- LED Mounting Method
- Front mounted and front emitting
- Brightness (cd/m²)
- 5000
- Transparency (%)
- 20 (P2.8*5.6), 70 (P3.9*7.8)
- Control Method
- Synchronous/Asynchronous
- Refresh Rate (Hz)
- 1920Hz/3840Hz
- Maintenance
- Front and rear maintenance
- Operating Ambient Temperature (°C)
- -20℃-40℃
- Ingress Protection
- IP30
- Average Lifespan
- MTBF≥10000 hours
- Power Input
- AC110-240V, 50/60Hz
- Features
- Clarity Transformed with Transparency
- Environment
- Indoor
