IceX Series
Product information
Starts from $12,000
Description
The IceX Series sets a new standard for outdoor transparency with its innovative design and high performance
Highlights
- High trasnperancy of 40%
- Weather Proof
- Customized Design
Details
The IceX Series features a pixel pitch range from P10.2 to P20.8, providing excellent visual quality for outdoor environments
New Generation Outdoor Transparency
Experience cutting-edge outdoor visuals with the IceX Series
High trasnperancy of 40%
Weather Proof
Customized Design
Technical Specifications
The product features are precision crafted to deliver exceptional performance and aesthetics.
- Model
- IceX Series
- Pixel Pitch (mm)
- P10.2, P15.6, P20.8
- Material
- Aluminum
- Cabinet Dimension (width/mm)
- 1000 x 500 for all models
- Pixel Configuration
- 1R1G1B, SMD 3 in 1, Direct emitting LEDs
- LED Chip Type
- Epistar 1921, Nationstar 3535, Nationstar 3935
- Mounting Method
- Front mounted and front emitting
- Resolution (dots/m²)
- P10.2: 9216, P15.6: 6400, P20.8: 4096
- Gray Scale
- 16 bit
- Brightness (cd/m²)
- ≥5000 for all models
- Closest Viewing Distance (m)
- P10.2: ≥5.5, P15.6: ≥4.4, P20.8: ≥4.5
- Viewing Angle
- Horizontal 140°, Vertical 120°
- Transparency (%)
- P10.2: 30%, P15.6: 10%, P20.8: ≥55, P20.8: ≥70
- Color Temperature (K)
- 6500K~9300K
- Luminance Uniformity
- ≥95%
- Scanning Method
- 1/2 scan
- Control Method
- Synchronous/Asynchronous
- Refresh Rate (Hz)
- 1920Hz/3840Hz
- Power Input
- AC110-240V, 50/60Hz
- Max Power Density (w/m²)
- P10.2/P15.6/P20.8: 800, P20.8: 600
- Average Power Density (w/m²)
- P10.2/P15.6/P20.8: 240, P20.8: 200
- Application
- Outdoor
- Environment
- Outdoor
- Operating Ambient Temperature (°C)
- -20°C~+50°C
- Ingress Protection
- IP65
- Average Lifespan (hours)
- ≥100,000
- MTBF (hours)
- ≥100,000
