Vibe Series
Product information
Starts from $15,000
Description
The Vibe Series introduces precision small pitch display technology for indoor LED video walls
Highlights
- Ultra Slim Cabinet
- DCP Technology
- Energy Saving
- Optional QCOB Technology
Details
Vibe Series includes various models with different pixel pitches and LED types, suitable for high-definition indoor applications

Fine Pitch Display
Introducing the Vibe Series, featuring precision small pitch display technology

Ultra Slim Cabinet
DCP Technology


Energy Saving
Technical Specifications
The product features are precision crafted to deliver exceptional performance and aesthetics.
- Pixel Pitches
- P1.25 mm, P1.53 mm, P1.86 mm, P1.99 mm, P2.5 mm
- LED Type
- Top 1010, Top 1212, Top 1515, Top 1817, Top 2121
- Module Resolution (W×H Pixel)
- 256×128, 208×104, 172×86, 160×80, 128×64
- Module Dimension (mm)
- 320×160
- Pixel/m²
- 640,000, 422,500, 288,906, 250,000, 160,000
- No. of Modules/Cabinet
- 2×3
- Servicing
- Front/Rear
- Cabinet Size (W×H×D)
- 640mm×480×49mm
- Cabinet Area (m²)
- 0.3072
- Cabinet Material
- Die-Cast Aluminum
- Cabinet Resolution
- 512×384, 416×312, 344×258, 320×240, 256×192
- Weight (KG)
- ≤7 KG
- Contrast Ratio
- 5000:1
- Colour Temperature (K)
- 5000-10000 Adjustable
- Brightness (nits)
- ≥600-800
- Viewing Angle (H/V)
- ≥160°/≥160°
- Max Power Consumption (W/m²)
- ≤450 (Common Cathode)
- Average Power Consumption (W/m²)
- ≤250
- Input Power Voltage
- AC220V±15%
- Drive Mode
- Constant Current Drive
- Frame Rate (Hz)
- 30-120 Hz
- Refresh Rate (Hz)
- ≥3840 Hz
- Colour Depth (bits)
- 16 bit
- Life Span (Hrs)
- 100,000
- Operating/Storage Temp (°C)
- -10+45/-20+60
- Operating/Storage Humidity (RH)
- 10-90%/10-70%
- IP Rating
- IP3X, IP5X with QCOB
